10톤중고타워크레인 JT150 풀셋트

상태양호하며 풀셋트로 판매합니다
자세한 문의는 011-9105-4394로 문의 바랍니다

50HZ 즉시 사용가능 모델 외 1대:아산공장

State Jianglu Machinery Factory Xiangtan Human China

lifting height(m)	multiplying power		climbing
loading radio of mec anism	loisting mechanism		JC 40%
	slewing mechanism		JC 25%
	trolley traveling mechanism		JC 25%
	traveling mechanism		JC 15%
	a=2		140
	a=4		90
max lifting capacity(t)	10
radius(m)	max radius	55
radius(m)	min tadius	2.5
hoisting mechanism speed	multiplying power			a=2	a=4
hoisting mechanism speed	lifting capacity(t)			5 / 2.5 / 1.5	20 / 40 / 60
hoisting mechanism motor	YZRW 250M, JC40%, 45KW, 962 rpm, width eddy current brake
slewing mechanism	speed	motor model	power	rotating speed
slewing mechanism	0.6r/min	YZR 132Mw-6	2 x 3.7 KW	908 rpm
trolley travelling mechanism	speed	motor model	power	rotating speed
trolley travelling mechanism	50/25/7.5 m/min	BF120 three speed motor	5/2.5/0.8 KW	1440/710/215 rpm
travelling mechanism	speed	motor model	power	rotating speed
travelling mechanism	24.5m/min	YZ160M2-6	2 x 7.5 KW	933 rpm
Climbimg mechanism	speed	motor model	power	rotating speed
	0.6m/min	Y132M-4	7.5KW	1500rpm
	working pressure		20 MPa
counter weight	Jib length(m)		weight
	40		12.38
	45		13.1
	50		15
	55		16.7
total power(KW)	75
working voltage(V)	380	working frequency(Hz)			50
working temperature(℃)	-20℃ ~ 40℃
dead weight	type jib length(m)	40	45	50	55
	rail-mounted type(t)	56.4	56.9	57.3	57.7
	Attached type(t)	73.9	74.4	74.8	75.2
	climbing type(t)	32.3	32.8	33.2	33.6
	stationary type(t)
